Pyslvs
Python Synthesis of Linkages and Verification Software

Open Source Multi-platform Planar Linkage Mechanism Simulation and Synthesis Software

Downloads

This program is free software; you can redistribute it and/or modify it under the terms of the Affero General Public License (AGPL) as published by Affero, Inc. version 3. This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.

The Latest Version on Github

Version 0.8.1 on Github

Or the Previous Version

Version 0.7 for Windows

Version 0.7 Source Code

Features

Planar Linkage Simulation and Dimensional Synthesis.

Python-Solvespace

Solvespace Geometric Contraint Solver Shared Library through SWIG.

Triangle Constraint Solver

Utilize SymPy to derivate symbolic equations and solve numerically.

PyQt5 and Eric6 Based

Developed on PyQt5 GUI and Eric6 IDE.

Real-Coded Genetic Algorithm

Real Coded Genetic Coordimate

Firefly Genetic Algorithm

Firefly is like other PSO algorithm.

Differential Evolution Algorithm

DE Evoluationary Method.

Multi-Link Simulation Video

Learn more about Pyslvs, its only 3mins

Examples

Planar Linkage Simulation and
Dimensional Four-bar Linkage Synthesis.

All Architecture Simulation Synthesis

Try The Latest Version

Download Now
